Teledyne DALSA Expands Rad-icon Family of CMOS X-Ray Detectors With 3030 Camera

WATERLOO, ONTARIO -- Teledyne DALSA announced its Rad-icon 3030 CMOS X-Ray detector.

The Rad-icon 3030 detector features 3096 x 3100 pixel resolution, an active area of 30.6 x 30.7 cm, and 99 micron pixel size. Rad-icon detectors deliver real-time frame rates of up to 30 fps, high sensitivity, and superb resolution in a large area device that is fully integrated and available with a fast, reliable Gigabit Ethernet or Camera Link interface.

The detectors offer a unique combination of higher resolution and fast imaging suitable for industrial x-ray inspection, scientific imaging, and non-destructive testing, including weld inspection, wire bond and printed circuit board (PCB) inspection, microfocus, computed tomography (CT) and other demanding industrial imaging applications.

"The Rad-icon 3030 detector is an ideal x-ray detector for the inspection of welds on boilers, tanks or pipelines," commented Thorsten Achterkirchen, Vice-President, X-Ray Imaging for Teledyne DALSA, "Cost-effective and efficient, with 30 fps frame rate and the flexibility of a Camera Link or Gigabit Ethernet interface, this latest Rad-icon x-ray detector is a good solution for a multitude of NDT applications."

Rad-icon digital x-ray cameras leverage Teledyne DALSA's advanced CMOS image sensing technology that enables the delivery of higher image quality than a-Si flat panels and image intensifier devices.

Other features include:
• 5 lp/mm resolution
• Energy range from 10 to 225 kV
• 14-bit digitization of images
• SDKs, drivers and programming support

For additional product information, visit http://www.teledynedalsa.com/rad-icon
