Mitutoyo Releases Latest Generation of Linear Scale

AURORA, IL --- Mitutoyo announces the ABSOLUTE AT1100, the latest generation of assembly-type linear scales that incorporate Mitutoyo’s electromagnetic induction technology, which provides resistance against contaminants such as cutting fluids, oil and water. The ABS AT1100 will be on display in booth E-5215 from September 12-17 during the International Manufacturing & Technology Show (IMTS) at McCormick Place in Chicago.

The innovative shape and location of the detector track in the aluminum frame provides a highly effective defense against the contamination of the scale and sensor, even in harsh environments. The sensor-to-scale air gap is approximately 0.4 mm, about 4x as wide as that of conventional optical or electromagnetic induction systems, thereby providing additional protection against dust or oil contamination.

ABS AT1100 Linear Scales are available up to an effective range of 3,040 mm and are compatible with FANUC Corporation’s serial interface and Mitsubishi Electric Corporation’s high-speed serial interface.

ABS AT1100 series scales are a special order item.

Mitutoyo America Corporation
965 Corporate Boulevard
Aurora, IL 60502
Phone: (630) 820-9666
Fax: (630) 820-2614
Email: [email protected]
Website: http://www.mitutoyo.com
