PISCATAWAY, NJ --- The MIPI Alliance releases MIPI I3CSM, Improved Inter-Integrated Circuit, a sensor interface specification that streamlines sensor integration in smartphones, wearables, Internet of Things (IoT) devices and automotive systems.
MIPI I3C Addresses Sensor Integration Challenges
MIPI I3C supports the adoption and proliferation of sensors in mobile-connected products. It makes it easier to integrate sensors in small space-constrained form factors, alleviates interface fragmentation, helps minimize pin count, and controls system-wide energy consumption. The specification gives developers a greater choice of design options, reduces system-level implementation costs, and helps shorten time-to-market for new applications.
MIPI I3C delivers these benefits by incorporating, consolidating and advancing I2C, SPI and UART with a new approach. The solution is comprehensive and scalable and provides a superset of features and functionalities while supporting legacy devices.
“The unified approach of MIPI I3C provides many strategic advantages for developers,” said Rick Wietfeldt, chair of the MIPI Alliance Technical Steering Group. “For example, with MIPI I3C, most types of I2C devices can coexist with I3C devices on the same bus, enabling vendors to migrate current I2C designs to the new standard. Likewise, newly designed MIPI I3C devices can work on existing legacy I2C buses.”
MIPI I3C specifies a chip-to-chip interface that can connect all sensors in a device to the application processor. It is implemented on a standard CMOS I/O using two wires. The specification achieves clock rates up to 12.5 MHz and provides options for higher performance, high-data rate modes. It uses a fraction of the power while providing more than an order of magnitude the bandwidth compared to I2C.
Versatility for Multiple Use Cases and Sensor Classifications
MIPI I3C can be used to build smartphones, virtual-reality head-mounted devices, robot drones, medical instruments, autonomous vehicles, industrial equipment, all-in-one computers, and TV remotes, among others.
The specification supports numerous sensor classifications and functions. Examples include accelerometers, touch screens, time-of-flight cameras, sonic/ultrasonic sensors, transducers, actuators and others. MIPI I3C also supports a range of biometric sensors and environmental sensors and can be used to interface sensors used for near-field communications, haptics feedback, and infrared or ultraviolet sensing.
Although MIPI I3C was originally developed to meet the needs of sensor applications, it can also be applied anywhere low-to-medium bandwidth devices benefitting from integrated data and control via byte-based transmission are found, such as power management and control interfaces. In addition, MIPI I3C will be utilized in other MIPI specifications under development, including MIPI Touch and MIPI Debug for I3C. MIPI Alliance welcomes industry participation in this work and invites member companies to collaborate in the creation of these forthcoming specifications.
Industry-Wide Collaboration on MIPI I3C
The MIPI Alliance Sensor Working Group developed MIPI I3C to ensure the specification benefits companies across the sensor ecosystem. The working group collaborated with the MEMS and Sensors Industry Group (MSIG) to survey both organizations’ members to assess sensor interface needs and industry technology gaps that traditional sensor interfaces did not address.
Companies participating in the working group include Advanced Micro Devices, Inc., Analogix Semiconductor, Inc., Cadence Design Systems, Inc., Google, Inc., Intel Corporation, Knowles Electronics, Lattice Semiconductor Corp., MediaTek Inc., NXP Semiconductor, Qualcomm Incorporated, QuickLogic, Sony Corporation, STMicroelectronics, Synopsys Inc. and others.
To learn more about MIPI I3C download the “Introduction to the MIPI I3C Standardized Sensor Interface” whitepaper: http://bit.ly/2gId6BL
For more information, please visit http://www.mipi.org
