Autonomous Navigation IoT Module Uses Sensors to Deliver Dead Reckoning Accuracy

LONDON --- Telit, announces commercial availability of the SL869-3DR, a GNSS module for global use which leverages information from internal gyros, accelerometers and a barometric pressure sensor to perform dead reckoning (DR) navigation for application areas like track & trace and in-vehicle systems. The module delivers accurate position data either directly from its multi-constellation receiver or from a fully autonomous DR system, requiring no connections to external devices or components other than an antenna for satellite signal reception and power. The module allows integrators to design zero-installation, in-vehicle navigation and tracking devices for fleets and other commercial or consumer applications that operate simply perched on the dashboard; connected only to vehicle power.

The SL869-3DR is a flash-memory based module capable of tracking three constellations simultaneously. The module integrates an array of micro electromechanical systems (MEMS) designed to provide it seven degrees of freedom (DOF). The innovative design of the internal sensor array in conjunction with the Telit MEMS-only Dead Reckoning (MoDR™) software and intellectual property, deliver the host device unparalleled portable, turn-key DR performance. The Telit MoDR™ solution ensures that reliable position, velocity and time (PVT) information is constantly available to the host application even when GNSS coverage is compromised, without the need for connection to the vehicle for wheel-ticks for speed or reverse-gear data. Its standard footprint lets navigation and tracking system integrators reuse existing device designs, eliminating complexity from external sensors and other apparatus, getting to market quickly with updated designs or product innovation.

The SL869-3DR is designed to support GPS, QZSS, GLONASS, Beidou and is Galileo ready. Telit MoDR™ technology boosts position accuracy in areas with adverse satellite reception conditions like urban canyons, overhead foliage, tunnels and parking garages. It integrates an embedded array of sensors including accelerometers, gyroscopes and a barometer (pressure sensor). An antenna ON, antenna sense (open / short circuit) feature, allows the host application to inform the user of problems with the connection to the external antenna. An additional LNA delivers better sensitivity in harsh environments, better enabling devices with integrated antennas. The module also features fast calibration and is pin-to-pin compatible with the SL869, SL869-V3 and SL869-ADR.

For more info:
VIDEO: https://www.youtube.com/watch?v=H9V0tIM8CDw
SL869: http://www.telit.com/gnss/sl869
SL869-V3: http://www.telit.com/gnss/sl869-v3
SL869-ADR: http://www.telit.com/gnss/sl869-adr
